TECHNICAL SPECIFICATIONS

Work Capacity (Depending on Feed)

• Corn stalk, corn cob, greenhouse waste, cotton stalk and similar agricultural wastes (t/h): 4–6 tons

• Branches, prunings, vineyard canes (t/h): 1–3 tons

• Cover boards, carpentry waste, nailed / non-nailed pallet waste (t/h): 1–3 tons

• Papel, plywood: 2–4 tons/hour

• Chipboard waste, MDF waste, tree bark (t/h): 2–4 tons

• Books, reels, rolls: 2–4 tons/hour

• Cardboard, boxes: 1–3 tons/hour

Knife System

• 54 swinging knives + 4 fixed knives

• Knives are Hardox 550 (55 HRC)

Knife Life

• Between 520 tons and 3,120 tons, depending on the type and cleanliness of the material being shredded

Hopper Rotation System

• Unit motor: 7.5 kW / 10 hp pump + 2 × 200 cc hydraulic motors

• Rotation via geared chain system, centered with castamide (engineering plastic) wheels

Rotor Specifications

• Rotor diameter: 950 mm

• Rotor length: 300 mm

Stress / Load Management

• Feed rate slows down when high material load is detected

• If the hopper jams due to hard-to-rotate material, it automatically reverses

• For certain materials, hopper rotation alternates left/right with a time-controlled system

Discharge Conveyor

• 80 cm × 570 cm rubber belt

• Closed tunnel-type housing to prevent dust and light materials from escaping

• 5.5 kW geared electric motor

Machine Weight

• 3,500 kg
